Produktgruppen > USB-over-Ethernet > DIGI AnywhereUSB

DIGI AnywhereUSB

USB Over IP Adapter

DIGI AnywhereUSB
  • EigenschaftenEigenschaften
  • BeschreibungBeschreibung
  • Weitere InformationenWeitere Informationen
  • PDFPDF
  • Network-enabled USB hub easily connects point-of-sale devices to a LAN
  • USB Over IP Adapter extends USB cabling distance beyond five meters
  • Creates systems redundancy and increases security since host PC can be moved to a remote location
  • Access and monitor devices over a TCP/IP connection
  • Simplifies operations and reduces IT support
  • SB ports appear to be locally attached and provide same Plug-and-Play user experience as on board USB ports
  • Designed for mission-critical enterprise applications like point-of-sale, industrial automation, mobile computing, access control and more
AnywhereUSB is the first remote networking solution to utilize USB Over IP technology, making it easy to connect USB devices anywhere  in a wired or wireless LAN, while eliminating the need for locally-attached host PCs. This Ethernet-attached solution provides five USB ports, which deliver the same Plug-and-Play user experience as onboard USB ports. AnywhereUSB software drivers are loaded onto a host PC or server, enabling remote devices to communicate with the host, without changing existing application software. Peripheral  devices can be centrally managed and monitored from a remote server or PC via an IP address. For retailers, relocating the host PC to a back office or other remote location translates to smaller point-of-sale stations, centralized management, reduced IT support and  instant system redundancy. Kiosk, ATM or pay-at-the-pump manufacturers can eliminate the PC inside the enclosure, reducing concerns of extreme changes in temperature or humidity.   AnywhereUSB is also an ideal solution for restaurant kitchens, access control systems, industrial automation or any environment that is volatile, not secure or where having an onsite PC is not  practical.
AnywhereUSB is compatible with bulk or interrupt type USB devices such as bar-code scanners, printers, fingerprint scanners, mice, pole displays, card readers and more. Our Watchport™/V USB Camera, Watchport Sensors and Edgeport® USB-to-Serial Converters are also fully compatible with AnywhereUSB.
Inside Out Networks, a Digi International company, is the leader in enterprise USB connectivity. Digi International, the leader in Connectware, makes device networking easy by developing products and technologies that are cost-effective and easy to use. With over 20 million ports shipped worldwide, Digi has been offering the highest levels of performance, flexibility, and quality since 1985.

ProdGrafik


Specifications AnywhereUSB /2 AnywhereUSB /5 AnywhereUSB /5M AnywhereUSB /TS AnywhereUSB /14
Interfaces
10/100Base-T Ethernet 1 RJ-45 1 RJ-45 1 RJ-45 1 RJ-45 2 RJ-45
USB 2 5 5 4 14
Serial N/A N/A N/A 4 RS-232 RJ-45 1 RS-232 DB9
FeaturesSSL AES-128
IP Address 1 static (fixed) address per unit
LEDs System and Port status
Power Supply Ships with 120-240VAC 50-60 Hz at 5VDC @ 3 amps max w/ locking barrel Includes 2 120-230VAC 50-60 Hz @8 amps max
Management CLI and AnywhereUSB web configuration tool
Other Shared Features Remote configuration utility; Multiple units supported per server; Field-upgradable software and firmware; Patented RealPort (serial over IP) and RealPort USB (USB over IP)
Serial Data Rates N/A N/A N/A Up to 230 Kbps per port Up to 230 Kbps per port
USB Downstream Power 500 mA per USB device
USB Compatibility USB 1.0, 1.1, 2.0
Note: USB storage devices and USB modems are not supported. Digi’s Edgeport/1 USB-to-serial converter may be used to connect a serial modem.
Operating Systems Windows® 8, Windows 7, Windows Vista®, Windows Server® 2012 R2, Windows Server 2008 R2, Windows Server 2003, Windows XP®, Windows XP Embedded
Multi-Host Connections N/A N/A Yes N/A Yes
Dimensions
(L x W x H)
2.38 in x 3.9 in x 1.0 in
(6.04 cm x 10.0 cm x 2.54 cm)
4.35 in x 7.20 in x 1.03 in
(11.05 cm x 18.29 cm 2.61 cm)
4.35 in x 7.20 in x 1.03 in
(11.05 cm x 18.29 cm 2.61 cm)
4.35 in x 7.20 in x 1.03 in
(11.05 cm x 18.29 cm 2.61 cm)
4.97 in x 17.00 in x 1.74 in
(12.62 cm x 43.18 cm x 4.42 cm),
Rack mountable 1U
Weight 5.0 oz (141.8 g) 10.0 oz (283.5 g) 10.0 oz (283.5 g) 10.0 oz (283.5 g) 40 oz (1134 g)
Environmental
Operating Temperature 32º F to 140º F (0º C to 60º C) 32° F to 131° F
(0° C to 55° C)
Storage Temperature -40° F to +185° F (-40° C to +85° C)
Relative Humidity 0% to 95% (non-condensing)
Network and Device Recommendations
Network Type 10/100 Mb switched EthernetDual 10/100 Mb switched Ethernet
USB Device Types Compatible with bulk or interrupt type USB devices; Isochronous devices not supported
Regulatory Approvals
Safety UL 1950/CSA 2.2 No. 950, EN60950, IEC-950
Emissions/Immunity CE, FCC Part 15 (Class B), EN55022, EN55024




Ordering Information
14-PORT MODEL
AW-USB-14 AnywhereUSB/14 with Multi-Host Connections
AW-USB-14-W AnywhereUSB/14 with Multi-Host Connections (International)
2-PORT MODEL
AW-USB-2 AnywhereUSB/2
AW-USB-2-W AnywhereUSB/2 (International)
5-PORT MODEL
AW-USB-5 AnywhereUSB/5 Gen 2
AW-USB-5M AnywhereUSB/5 with Multi-Host Connections
AW-USB-5M-W AnywhereUSB/5 with Multi-Host Connections (International)
AW-USB-5-W AnywhereUSB/5 Gen 2 (International)
TS MODEL PART NUMBER
AW-TS-44 AnywhereUSB TS - 4 serial and 4 USB ports
AW-TS-44-W AnywhereUSB TS - 4 serial and 4 USB ports (International)
